Magic2 is the innovative invisible sliding door system outside the wall, for wooden doors, with soft-closing.
Magic2 is the multi-patented system, designed and produced by Terno Scorrevoli, totally Made in Italy.
A product that integrates the magic of architectural minimalism and the smoothness of an extremely tested system - today in version 2.
Dampers with adjustable positioning: Dampers were designed to be independent of wall-spacer wheels. They're suitable to be moved into the track to allow door positioning adjustment.
Wall-spacer wheels: Wheels are positioned on the door extremities, in order to protect the door from wall contact, when the wall surface is not plane.
Patented adjustment system Magic2 integrates the following door adjustments:
- Door height adjustment from the floor,
- Micrometric adjustment of the door from the wall,
- Micrometric adjustment of door parallelism to the wall
- Door adjustments of wall distance and parallelism are meant to compensate for possible irregularities of the wall.
All adjustments are available in the top of the sliding trolley, without removing the door. The practical anti-jumping system Magic2 features two turning antijumping activation elements, each equipped with a safety lever, allowing for easy rotation with no tools required. Safety levers, clearly visible, will have to be removed once the anti-jumping system is activated.
Silent lower guide: To further increase sliding quality, the reinforced lower guide in Zamak (reliable and versatile) slides in a silent plastic profile.
Patented bottom wheels designed for better sliding: Bottom wheels are equipped with a patented suspension spring system, with a larger diameter, bigger bearing and steel pivots. The rubber surface has been enlarged as well, to reinforce wheels and improve sliding quality. The rubber does not leave any trace or sign on sliding surfaces like floors and walls, and it does not deform over time.
Width: 680 ÷ 1100 mm
Weight: Max 80 kg
Close to floor: 10 mm
Door, Lock and Handles are NOT included!
